Biogas upgrading is a sustainable solution to generate renewable energy from organic waste. However, the presence of carbon dioxide (CO2) can reduce the energy efficiency. This is where our CO2 separator comes in. Specifically, the CO-0302SES is our smallest CO2 separator, with a diameter of 1 inch (body part) and a length of 380 mm, suitable for scale testing.
This innovative separator uses advanced membrane technology to efficiently remove CO2 from biogas. This improves the quality of biogas, making it more efficient for use as an energy source by efficiently collecting CO2.
The mini CO2 Separator CO-0302SES is a device designed to offer optimal performance in the separation of CO2 from biogas, significantly improving the final quality of the biomethane thanks to its optimized operating conditions and specifications.
Regarding the operating conditions, the maximum use-environment temperature is 60 ºC, under a maximum pressure of 10 barg and with a relative humidity of the feed gas less than or equal to 80%. Here, the temperature of the feed gas can be between 5-60 ºC.
About its product specifications, the mini CO2 Separator CO-0302SES of 1.7 kilos has a hollow fiber of polyimide resin, thus providing an excellent performance. The housing is made of stainless steel, ensuring high durability and corrosion resistance, even under adverse conditions.
Thus, the mini CO2 Separator CO-0302SES is an advanced and reliable solution to upgrade biogas through the efficient elimination of CO2, standing out for its high-quality materials and a design of robust and efficient dimensions. For further information about the specifications of our mini CO2 separator, download our data sheet.
